FRP Rod For Optical Cable Reinforcement
FRP Rod, a dielectric composite cable strength member. Fiberglass cable core reinforced rod is a new type of high-performance composite material, it is to use epoxy resin as foundation combined with the strength of glass fiber through pultrusion technology to produce a new type of high performance non-metallic composite material.
FRP rod core overcomes the defects of the traditional metal fiber reinforced parts, FRP strength member features excellent anti-corrosion, electromagnetic interference free, high tensile strength, low weight, saving energy and environmentally friendly, which are now widely used in various optical fiber cables. Its tensile strength provides the cable protection during installation and its rigidity prevents cable buckling during the life of the cable.
Technical details of fiberglass cable reinforced rod:
Values
Tensile strength (Mpa)
≥1100
Tensile modulus (Gpa)
≥50
Flexural strength (Mpa)
≥1100
Flexural modulus (Gpa)
≥50
Elongation at break (%)
≤4
Coefficient of linear thermal expansion (-30-80℃) (1/℃)
<8×10-6
Diameter range (mm)
0.4-5
Density (g/cm³)
2.05~2.15
Minimum bending radius (mm)
40×D
High temperature bending test (50D,100℃,120h)
No bur, cracks and break
Minimum order quantity
100 kilometers
Property
Application of fiberglass rod reinforced cable:
Due to the excellent features, fiberglass rods are widely used in the reinforcement of cables for various fields, such as:
Railway cable; telecommunication optical cable; power plant cable; wind power mill cable; photovoltaic power generation cable; mining cable; underwater cable; weak current engineering; intelligent building; computer room transformation; security monitoring
Features of fiberglass optical cable reinforced rod:
1) Not sensitive to the lightning strike, applied to the areas which are common with frequent lightning and rain;
2) Not obstructed by induced current and can be installed close to the power unit and device;
3) Corrosion free, no harmful gas that would affect the optical transmission indicators;
4) Has the characteristics of high tensile and light weight;
5) Bullet-proof, ant-proof and anti-tooth proof.
